5083 Aluminum Sheet
Features
1, The main ingredient of this series aluminum sheet is magnesium
element and the content is between 3% and 5%. It is also called
aluminum magnesium alloy.
2, With its low density, it features high tensile strength and
elongation.
3 T his series aluminum sheet is a commonly used and mature series
in China.
5000 Aluminum Sheet Specifications
1,Sheets thickness: 0.15-2.0mm
2,Plate thickness: 2.0mm-250mm
3,Temper: Soft and Variety Hard temper (O-H116) (T2-T6)
4,Customer requirements are acceptable
5000 Aluminum Sheet Applications
1, With the same area of other series, the weight of this aluminum
sheet is lighter. As a result, it is used in aviation, such as in
the fuel tanks in airplanes.
2, It is widely used in conventional industries.
3, This aluminum sheet can be used in continuously casting and
rolling. It can be hot rolled. As a result, it can be used in
oxidation and deep processing.
5083 Aluminum Sheet
With excellent corrosion resistance and weldability, together with
high strength, this alloy was designed for welded structures
requiring maximum joint strength and efficiency. Can be anodized
for increased corrosion resistance, but does not lend itself to
decorative applications. Not meant to be a machining alloy, but can
be machined fairly well with proper preparations. Because of its
relatively high magnesium content, the workability rating would
only be fair. Non-heat treatable. Typical applications include
large marine craft, containers, railroad cars, structurals and
elevator cars.
5754 Aluminum Sheet
Excellent corrosion resistance and, unlike the other magnesium
alloys, it maintains that rating when functioning in the150-300
degrees F range where the others would be prone to stress
corrosion. Not a decorative alloy but well adapted to the applied
finishing processes. High strength, excellent weldability, fair
formability, and poor machinability. Non-heat treatable. Typical
applications include dump bodies, exhaust stacks, marine
components, and chemical handling vessels.
Our Aluminium sheets products list including
1,Coil sheet, Mill finish aluminium sheet (MFP)
2,Color coated aluminium sheet
3,Checkered plate (TLP in nickname of , checker plate, Tread plate,
diamond plate, chequer plate)
4,Mirror finish aluminium sheet (Mirror reflective aluminium sheet)
5,Anodised aluminium sheet (two side anodised, only silver color
available.)
6,Stucco aluminium sheet (orange skin type, variations stucco type)
7,CTP base board
8,PS base board
9,CC Lids/cap plate
