6063 T5 Aluminium Guide Rails Extrusion Profiles

Product Categories

Shanghai Bozhong Metal Group Co., Ltd.

Contact Now

6063 T5 Aluminium Guide Rails Extrusion Profiles

Ask Lasest Price
Brand Name :	Zhongduo
Model Number :	6000 Series
Certification :	CE, ISO, RoHS
Price :	USD15-50000/pcs
Payment Terms :	L/C, T/T
Supply Ability :	5000Tons/month
Delivery Time :	22-30days

Add to Cart

Product Details
Company Profile

6063 T5 Aluminium Guide Rails Extrusion Profiles

Mechamical Properties
Alloy	Temper	Tensile Strength	Yield strength	Stretching rate	HV	HW
6061	T6	≥265Mpa	≥245Mpa	≥8%
6063	T5	≥160Mpa	≥110Mpa	≥8%	HV≥58	HW≥8
6063	T6	≥205Mpa	≥180Mpa	≥8%

Electrophoresis Coating Profile
Class	Anodizing Coating		Pating Coating	Composite Coating	Coating Pencil Hardness
	Average	Partial
A	≥10um	≥8um	≥12um	≥21um	≥3H
B	≥10um	≥8um	≥7um	≥17um	≥3H

Powder Coating And Wooden Grain Transfer Printing
Coating thickness	Coating indentation hardness	Coating adhesion
40-120um	Indentation resistance≥80	Class 0

Aluminium Profile for New Energy Vehicle Power Supply Project Parts with Competitive Price and Excellent Design

What is Aluminium Extrusion?
Extrusion is the introduction of a heated aluminium ingot into a container and forcing it at high pressure through the profiled opening of a die which corresponds to the cross-section of the extrusion.

Why Aluminium Extrusion?
More and more people are realizing the benefits that aluminium extrusion can offer: The unique properties of aluminium in combination with the virtually unlimited opportunities the aluminium extrusion process gives to adapt product shape to innovate, reduce cost and maximize efficiency. From automotive to architecture, furniture to facades, lifts to lighting, the use of aluminium extrusions is extensive and new applications are being discovered every day.
Besides, the cost of aluminium extrusion is significantly lower than other processes, such as casting or forming and other extrusion processes such as plastic. Costs vary depending on the size, type, and complexity of extrusion.
In addition, the low density of aluminium results in a lightweight profile compared to other materials, which is easy to handle down the supply chain, as well as being cheaper and more environmentally friendly to transport.

How to change the design into a real product?
CAD drawings evaluation as per extrusion natures-
CAD drawings finalized-
Tooling drawings approved and 100% prepayment for tooling fee-
Tooling development-
Extrusion-
Off-tool samples for approval-
30% Prepayment for bulk production-
Bulk production-
Balance payment-
Delivery

1. Technician team: over 30 years of experience in Aluminium extrusion for industrial application.

2. Rich source of Aluminium ingot locally.
3. Export staff embodied with fluent English communication skills, good knowledge in aluminium extrusion industries, and exports. Stable and reliable to help to sort out all problems.
4. Wide range of Aluminium alloy materials available.
5. Undertake any quality problems unconditionally.

Q1: Any MOQ required?

A: We accept any quantity you may need. But there will be set-up charge for small order.
Q2: What is the lead time for tooling and off-tool samples?
A: For small tooling (External size less than 229mm), it takes about 10-15 days for tooling and about 5 days for off-tool samples preparing.
Q3: How about the payment terms?
A: For tooling, 100% prepayment by TT bank; for bulk production, 30% prepayment by TT bank, and balance against delivery.
Q4: Will you send videos or pictures in the processing?
A: Yes, we will keep you updated about the status here by sending videos or pictures.

You can start with a small trial. Just send me your drawings!
Look forward to hearing from you.
