    ASME SA387 Pressure Vessel Plate Hot Rolled Grade 11 Class 1

    Ask Lasest Price
    Brand Name : BOZHONG
    Model Number : SA387
    Certification : ISO, SGS,BV,TUV,3.1
    Price : USD.9-1.9/KG FOB SHANGHAI
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10000TONS PER MONTH
    Delivery Time : 7-35DAYS ACCORDING TO YOUR ORDER QUANTITY
    • Product Details
    • Company Profile

    ASME SA387 Pressure Vessel Plate Hot Rolled Grade 11 Class 1

    ASME SA387 Specification

    The ASME SA387 standard covers the supply of weldable chrome molybdenum alloy steel plates for pressure vessels used in elevated temperature service.

    The added molybdenum and chromium provides excellent corrosion resistance and high temperature resistance respectively.

    ASME SA387 standard plates are used by the world’s leading fabricators who in turn, supply primarily to the oil and petrochemical industry.

    Sourced from some of Western Europe’s & India's finest steel mills, Prosaic Steel and Alloys stock a wide range of ASME SA387 Class 2 plates which are available for shipment worldwide.

    Specifications ASME SA387 Grade 5 Alloy Steel Plates:
    Chromium & Molybdenum content (according to the ASME specification):

    Designation Nominal Chromium
    Content (%)    		 Nominal Molybdenum
    Content (%)
    SA387 Grade 5 5.00% 0.50%

    Chemical Requirements for ASME SA387 Grade 5 Class 2 Plates

    Elements (%) ASME SA387 Grade 5 ASME SA387 Grade 9 ASME SA387 Grade 11 ASME SA387 Grade 12 ASME SA387 Grade 22 ASME SA387 Grade 91
    Carbon Heat 0.15 max 0.15 max 0.05–0.17 0.05–0.17 0.05–0.15a 0.08–0.12
    Product 0.15 max 0.15 max 0.04–0.17 0.04–0.17 0.04–0.15a 0.06–0.15
    Manganese Heat 0.30–0.60 0.30–0.60 0.40–0.65 0.40–0.65 0.30–0.60 0.30–0.60
    Product 0.25–0.66 0.30–0.60 0.35–0.73 0.35–0.73 0.25–0.66 0.25–0.66
    Phosphorus, max Heat 0.025 0.025 0.025 0.025 0.025 0.020
    Product 0.025 0.025 0.025 0.025 0.025 0.025
    Sulphur, max Heat 0.025 0.025 0.025 0.025 0.025 0.010
    Product 0.025 0.025 0.025 0.025 0.025 0.012
    Silicon Heat 0.50 max 1.00 max 0.50–0.80 0.15–0.40 0.50 max 0.20–0.50
    Product 0.55 max 1.05 max 0.44–0.86 0.13–0.45 0.50 max 0.18–0.56
    Chromium Heat 4.00–6.00 8.00–10.00 1.00–1.50 0.80–1.15 2.00–2.50 8.00–9.50
    Product 3.90–6.10 7.90–10.10 0.94–1.56 0.74–1.21 1.88–2.62 7.90–9.60
    Molybdenum Heat 0.45–0.65 0.90–1.10 0.45–0.65 0.45–0.60 0.90–1.10 0.85–1.05
    Product 0.40–0.70 0.85–1.15 0.40–0.70 0.40–0.65 0.85–1.15 0.80–1.10
    Nickel Heat - - - - - 0.40
    Product - - - - - 0.43
    Vanadium Heat - 0.04 max - - - 0.18–0.25
    Product - 0.04 max - - - 0.16–0.27
    Columbium Heat - - - - - 0.06–0.10
    Product - - - - - 0.05–0.11
    Nitrogen Heat - - - - - 0.030–0.070
    Product - - - - - 0.025–0.080
    Aluminum, max Heat - - - - - 0.02
    Product - - - - - 0.02
    Titanium, max Heat - - - - - 0.01
    Product - - - - - 0.01
    Zirconium, max Heat - - - - - 0.01
    Product - - - - - 0.01
    a The carbon content for plates over 5 in. [125 mm] in thickness is 0.17 max on product analysis.

    Mechanical Properties and Tensile Requirements for ASME SA387 Grade 5 Class 1 Plates

    Grades 2 and 12 Grade 11 Grades 22, 21, 5, 9, 21L, 22L
    Tensile strength, ksi [MPa] 55 to 80 [380 to 550] 60 to 85 [415 to 585] 60 to 85 [415 to 585]
    Yield strength, min, ksi [MPa] 33 [230] 35 [240] 30 [205]
    Elongation in 8 in. [200 mm], min, % a 18 19 -
    Elongation in 2 in. [50 mm], min, % a 22 22 18
    Reduction of area, min, % - - 45 b
    - - 40 c
    a See Specification A20/A20M, elongation adjustments.
    b Measured on round test specimens.
    c Measured on flat specimen.

    Mechanical Properties and Tensile Requirements for ASME SA387 Grade 5 Class 2 Plates

    Grade 2 Grade 11 Grade 12 Grades 22,
    21, 5, 9    		 Grade 91
    Tensile strength, ksi [MPa] 70 to 90
    [485 to 620]    		 75 to 100
    [515 to 690]    		 65 to 85
    [450 to 585]    		 75 to 100
    [515 to 690]    		 70 to 90
    [585 to 760]
    Yield strength, min,
    ksi [MPa]/(0.2 % offset)    		 45[310] 45[310] 40[275] 45[310] 60[415]
    Elongation in 8 in.
    [200 mm], min, % b    		 18 18 19 - -
    Elongation in 8 in.
    [50 mm], min, % b    		 22 22 22 18 18
    Reduction of area, min, % - - - 45 b -
    - - - 45 c -
    a Not applicable to annealed material.
    b See Specification A20/A20M, elongation adjustments.
    c Measured on round test specimens.
    d Measured on flat specimen.
